FADA 2800 Series Gearbox
The input speed range of the FADA 2800 Series marine gearbox is 500 – 1400 RPM. The reduction ratio range is 3.6538 – 12.4211 and transfer capacity range is 1.4269 – 2.0594 kW/RPM.FADA 2800 Series marine gearbox is composed of Input coupling, control system, output coupling, oil cooler, oil filter, oil pressure gauge and other important components. FADA 2800 Series marine gearbox can provide mechanical control system.All of our FADA gearboxes are approved by CCS, and we are able to provide BV LR ABS DNV&GL RS and other classification societies based on customer requirement with extra cost.As an official marine power pack packager of FADA, SeaMac provide complete propulsion system and power system for all kinds of ships all around the world. Mainly including marine engine, gearbox, shaft, propeller, marine genset, electric control lever system and other marine accessories. We also provide full life cycle services for all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages Of FADA 2800 Marine Gearbox
- Gearbox novel structure, so that its use becomes very reliable. The excellent design makes the gearbox and engine arrangement more soft and smooth.
- Small in size, clear in weight. The ease of use and maintenance is fully considered in the design.
- With excellent machine performance, good design effectively reduce the noise, reduce the vibration.
- European standard manufacturing, making the structure strong and durable, smooth work.
- Excellent deceleration effect and bearing propeller thrust.
- Professional gearbox specialists and after-sales service, spare parts directly available from stock.
General Specifications of FADA Gearbox 2800 Series
| Rated Speed: |
500 – 1400 RPM
|
| Actual Ratio: |
3.6538 – 12.4211
|
| Capacity: |
1.4269 – 2.0594 kW / RPM
|
| Net Weight: | 5000 – 8650 kg |
FADA 2800 Series Marine Gearbox
This is a list of all of FADA 2800 series marine gearbox.
FADA JT2800/1 Marine Gearbox
Gearbox Model: JT2800/1 Marine Gearbox
Input Speed Range: 500 – 1400RPM
Reduction Ratio: 7.4858 – 12.4211
Trans. Capacity: 1.7200 – 2.0594 kW / RPM
FADA JT2800 Marine Gearbox
Gearbox Model: JT2800 Marine Gearbox
Input Speed Range: 500 – 1400RPM
Reduction Ratio: 5.0817 – 11.4895
Trans. Capacity: 1.4269 – 2.0594 kW / RPM
FADA JD2800 Marine Gearbox
Gearbox Model: JD2800 Marine Gearbox
Input Speed Range: 500 – 1400 RPM
Reduction Ratio: 3.6538:1 – 6.1053:1
Trans. Capacity: 1.7000 – 2.0594 kW / RPM
