FADA 900 Series Gearbox
The input speed range of the FADA 900 Series marine gearbox is 750 – 1800 RPM. The reduction ratio range is 1.963 – 16.430 and transfer capacity range is 0.338 – 0.800 kW/RPM.FADA 900 Series marine gearbox is composed of Input coupling, control system, output coupling, oil cooler, oil filter, oil pressure gauge and other important components. FADA 900 Series marine gearbox can provide mechanical control system. To meet the different requirement of coupling with different diesel engine brands and models, FADA 900 Series marine gearbox are offered in different sizes of housing SAE 00 0.All of our FADA gearboxes are approved by CCS, and we are able to provide BV LR ABS DNV&GL RS and other classification societies based on customer requirement with extra cost.As an official marine power pack packager of FADA, SeaMac provide complete propulsion system and power system for all kinds of ships all around the world. Mainly including marine engine, gearbox, shaft, propeller, marine genset, electric control lever system and other marine accessories. We also provide full life cycle services for all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages Of FADA 900 Marine Gearbox
- Gearbox novel structure, so that its use becomes very reliable. The excellent design makes the gearbox and engine arrangement more soft and smooth.
- Small in size, clear in weight. The ease of use and maintenance is fully considered in the design.
- With excellent machine performance, good design effectively reduce the noise, reduce the vibration.
- European standard manufacturing, making the structure strong and durable, smooth work.
- Excellent deceleration effect and bearing propeller thrust.
- Professional gearbox specialists and after-sales service, spare parts directly available from stock.
General Specifications of FADA Gearbox 600 Series
| Rated Speed: | 750 – 1800 RPM |
| Actual Ratio: |
1.963 – 16.430
|
| Capacity: |
0.338 – 0.800 kW / RPM
|
| Net Weight: | 1600 – 3000 kg |
FADA 900 Series Marine Gearbox
This is a list of all of FADA 900 series marine gearbox.
FADA JT900/1 Marine Gearbox
Gearbox Model: JT900/1 Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 9.585 – 16.430
Trans. Capacity: 0.338 – 0.699 kW / RPM
FADA JT900 Marine Gearbox
Gearbox Model: JT900 Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 4.6467 – 9.5212
Trans. Capacity: 0.441 – 0.800 kW / RPM
FADA JD900A Marine Gearbox
Gearbox Model: JD900A Marine Gearbox
Input Speed Range: 750 – 1600 RPM
Reduction Ratio: 3.955 – 5.944
Trans. Capacity: 0.600 – 0.706 kW / RPM
FADA J900A Marine Gearbox
Gearbox Model: J900A Marine Gearbox
Input Speed Range: 750 – 1600 RPM
Reduction Ratio: 1.963 – 4.063
Trans. Capacity: 0.629 – 0.700 kW / RPM
