Gearbox Model: JD700 Marine Gearbox
Input Speed: 1000 – 2100 RPM
Actual Ratio: 4.18 – 6.05
Trans. Capacity: 0.500 – 0.550 kW / RPM
FADA New Series Gearbox
FADA New series Gearbox products including X40 50 D50 D145 345 D345 D345 – 1 450 JD700
FADA New series Gearbox have the ability to reducing speed, ahead and astern, clutching and disclutching and carrying the propeller thrust.
The said gearbox is somewhat new in construction, reliable in operation, smooth in engaging, light in weight, small in bulk, easy in maintenance and durable in application. The said gearbox is somewhat new in construction, reliable in operation, smooth in engaging, light in weight, small in bulk, easy in maintenance and durable in application.
The said products can be used in passenger or cargo boats, fishing boats, tow boats, tugs and high-speed vessels etc., which are perfect selections to make the engine in good condition and to get high efficiency.
As an official marine power pack packager of FADA, SeaMac provide complete propulsion system and power system for all kinds of ships all around the world. Mainly including marine engine, gearbox, shaft, propeller, marine genset, electric control lever system and other marine accessories. We also provide full life cycle services for all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages Of FADA New Series Gearbox
- Small in size, clear in weight. The ease of use and maintenance is fully considered in the design.
- With excellent machine performance, good design effectively reduce the noise, reduce the vibration.
- Excellent deceleration effect and bearing propeller thrust.
- Extend the life of the engine and transmission components, improve and enhance the power of the car.
- Reduce the dynamic load on the transmission system and improve the transmission efficiency.
- Professional gearbox specialists and after-sales service, spare parts directly available from stock.
Find FADA New Series Gearbox by Series
This is a list of all of FADA New series Gearbox.
New Series Gearbox |
FADA D450 Gearbox
Gearbox Model: D450 Marine Gearbox
Input Speed: 1000 – 2100 RPM
Actual Ratio: 4.000 – 6.000
Trans. Capacity: 0.279 – 0.331 kW / RPM
FADA 450 Gearbox
Gearbox Model: 450 Marine Gearbox
Input Speed: 1000 – 2100 RPM
Actual Ratio: 2.04 – 4.06
Trans. Capacity: 0.280 – 0.331 kW / RPM
FADA D345/1 Gearbox
Gearbox Model: D345 / 1 Marine Gearbox
Input Speed: 750 – 2500 RPM
Actual Ratio: 5.52 – 7.06
Trans. Capacity: 0.147 – 0.200 kW / RPM
FADA D345 Gearbox
Gearbox Model: D345 Marine Gearbox
Input Speed: 750 – 2500 RPM
Actual Ratio: 4.050 – 5.471
Trans. Capacity: 0.184 – 0.257 kW / RPM
FADA 345 Gearbox
Gearbox Model: 345 Marine Gearbox
Input Speed: 750 – 2500 RPM
Actual Ratio: 3.00 – 5.00
Trans. Capacity: 0.147 – 0.243 kW / RPM
FADA D145 Gearbox
Gearbox Model: D145 Marine Gearbox
Input Speed: 750 – 2000 RPM
Actual Ratio: 3.04 – 5.81
Trans. Capacity: 0.070 – 0.100 kW / RPM
FADA D50 Gearbox
Gearbox Model: D50 Marine Gearbox
Input Speed: 1000 – 2500 RPM
Actual Ratio: 1.97 – 5.88
Trans. Capacity: 0.027 – 0.039 kW / RPM
FADA 50 Gearbox
Gearbox Model: 50 Marine Gearbox
Input Speed: 1000 – 2500 RPM
Actual Ratio: 2.0333 – 4.5000
Trans. Capacity: 0.025 – 0.039 kW / RPM
FADA X40 Gearbox
Gearbox Model: X40 Marine Gearbox
Input Speed: 750 – 2000 RPM
Actual Ratio: 2.07 – 3.65
Trans. Capacity: 0.023 – 0.029 kW / RPM
