FADA FD135A Marine Gearbox

The speed input range of the FADA FD135A marine gearbox is 750 – 2000 RPM, the center distance is 225 mm, the reduction ratio range is 2.03 – 5.81, the transmission capacity range is 0.070 – 0.100 kW / RPM, the rated propeller thrust is 30 KN. When ahead running, the direction of input betwen ouput is opposite.

FADA FD135A marine gearbox is composed of transmission shaft, output coupling, input coupling, oil pressure gauge, oil Filter, control system, oil pump and other important components.

FADA FD135A marine gearboxes provides of control system which are mechanical, To meet the different requirement of coupling with different engine brand and models.

All of our FADA marine gearbox can provide CCS classification certificate, some of series can provide international classifications with extra costs which mainly including French BV, British LR, American ABS, Japanese NK , Norway DNV-GL, Russia RS, South Korea KR, Italy RINA and other classification societies.

Advantages Of FADA FD135A Marine Gearbox

• Multi-functional design: with reversing, gripping and deceleration functions, it can be used with various equivalent torque Marine diesel engines to form an efficient unit to meet the various power needs of the ship.

• Compact structure and a variety of control methods: The compact structure of the gearbox, sensitive and convenient operation, support a variety of control methods, can be easily remote operation, improve the convenience of ship driving and machine integration.

• Durable and easy to maintain: The advanced design makes the gearbox connection softer, easier to maintain, and has a long service life. Large transmission power, small size, light weight, optimize space use and improve efficiency.

• Flexible coupling and beautiful appearance: equipped with toothed elastic input coupling and connecting cover, can be connected with a variety of flywheel and flywheel shell, easy to install, and beautiful appearance, with good visual effect.

• Deceleration effect and propeller thrust: with excellent deceleration effect, and can withstand large bearing and propeller thrust, to ensure the stable operation of the ship’s power system.

• Professional service and spot spare parts: Provide professional transmission expert services to ensure the long-term stable operation of equipment, and spare parts are directly available from the spot to ensure timely maintenance and replacement.

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
