Gearbox Model: MG75.90 Marine Gearbox
Input Speed Range: 300 – 950 RPM
Reduction Ratio: 1.9773 – 6.0481
Trans. Capacity: 7.310 – 22.746 kW / RPM
FADA MG Series Gearbox
FADA MG Series Gearbox Its rated output speed is 300-950r/min, the reduction ratio range is 2 : 1 – 6 : 1, and the rated transmission capacity is 0.490 – 22.746 kw / r / min This series of products is manufactured by FADA with the license technology introduced by German Lohmann Company, and after more than 30 years of digestion, absorption and optimization design, it is mainly used in large bulk carriers, ocean fishing vessels, oil tankers, ships, etc. The product has reliable performance and convenient operation, and is the best partner for medium-speed diesel engines at home and abroad.
As an official marine power pack packager of FADA, SeaMac provide complete propulsion system and power system for all kinds of ships all around the world. Mainly including marine engine, gearbox, shaft, propeller, marine genset, electric control lever system and other marine accessories. We also provide full life cycle services for all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages Of MG Series Marine Gearbox
- Gearbox novel structure, so that its use becomes very reliable. The excellent design makes the gearbox and engine arrangement more soft and smooth.
- With excellent machine performance, good design effectively reduces the noise and vibration.
- European standard manufacturing, making the structure strong and durable, smooth work.
- Excellent deceleration effect and bearing propeller thrust.
- Professional gearbox specialists and after-sales service, spare parts directly available from stock.
Find FADA MG Gearboxs by Series
This is a list of all of FADA MG series marine gearbox.
MG |
FADA MG70.85 Marine Gearbox
Gearbox Model: MG70.85 Marine Gearbox
Input Speed Range: 300 – 950 RPM
Reduction Ratio: 1.9762 – 5.9885
Trans. Capacity: 6.468 – 19.600 kW / RPM
FADA MG70.76A Marine Gearbox
Gearbox Model: MG70.76A Marine Gearbox
Input Speed Range: 300 – 900 RPM
Reduction Ratio: 1.9347 – 5.9891
Trans. Capacity: 5.352 – 16.578 kW / RPM
FADA MG70.76 Marine Gearbox
Gearbox Model: MG70.76 Marine Gearbox
Input Speed Range: 400 – 1000 RPM
Reduction Ratio: 1.9347 – 5.9891
Trans. Capacity: 4.968 – 15.392 kW / RPM
FADA MG66.75 Marine Gearbox
Gearbox Model: MG66.75 Marine Gearbox
Input Speed Range: 300 – 950 RPM
Reduction Ratio: 2.0135 – 5.9286
Trans. Capacity: 4.970 – 14.640 kW / RPM
FADA MG63.71 Marine Gearbox
Gearbox Model: MG63.71 Marine Gearbox
Input Speed Range: 300 – 1000 RPM
Reduction Ratio: 2.0139 – 5.9526
Trans. Capacity: 4.340 – 12.840 kW / RPM
FADA MG60.66 Marine Gearbox
Gearbox Model: MG60.66 Marine Gearbox
Input Speed Range: 400 – 1200 RPM
Reduction Ratio: 2.0123 – 6.1161
Trans. Capacity: 3.305 – 10.054 kW / RPM
FADA MG52.62 Marine Gearbox
Gearbox Model: MG52.62 Marine Gearbox
Input Speed Range: 400 – 1200 RPM
Reduction Ratio: 1.9895 – 6.0750
Trans. Capacity: 2.560 – 7.818 kW / RPM
FADA MG52.59 Marine Gearbox
Gearbox Model: MG52.59 Marine Gearbox
Input Speed Range: 400 – 1200 RPM
Reduction Ratio: 2.0170 – 5.9250
Trans. Capacity: 2.479 – 7.289 kW / RPM
FADA MG49.57 Marine Gearbox
Gearbox Model: MG49.57 Marine Gearbox
Input Speed Range: 400 – 1200 RPM
Reduction Ratio: 1.9918 – 5.9108
Trans. Capacity: 2.095 – 6.218 kW / RPM
FADA MG49.54 Marine Gearbox
Gearbox Model: MG49.54 Marine Gearbox
Input Speed Range: 400 – 1200 RPM
Reduction Ratio: 2.0153 – 6.0412
Trans. Capacity: 1.866 – 5.593 kW / RPM
FADA MG45.52 Marine Gearbox
Gearbox Model: MG45.52 Marine Gearbox
Input Speed Range: 400 – 1400 RPM
Reduction Ratio: 2.0373 – 5.9809
Trans. Capacity: 1.609 – 4.723 kW / RPM
FADA MG45.49 Marine Gearbox
Gearbox Model: MG45.49 Marine Gearbox
Input Speed Range: 400 – 1400 RPM
Reduction Ratio: 1.9377 – 5.9887
Trans. Capacity: 1.493 – 4.614 kW / RPM
FADA MG42.45 Marine Gearbox
Gearbox Model: MG42.45 Marine Gearbox
Input Speed Range: 400 – 1600 RPM
Reduction Ratio: 1.9389 – 5.9923
Trans. Capacity: 1.114 – 3.537 kW / RPM
FADA MG39.41 Marine Gearbox
Gearbox Model: MG39.41 Marine Gearbox
Input Speed Range: 400 – 1600 RPM
Reduction Ratio: 1.9377 – 5.9887
Trans. Capacity: 0.855 – 2.644 kW / RPM
FADA MG36.39 Marine Gearbox
Gearbox Model: MG36.39 Marine Gearbox
Input Speed Range: 400 – 1800 RPM
Reduction Ratio: 2.0121 – 5.9885
Trans. Capacity: 0.671 – 1.998 kW / RPM
FADA MG32.35 Marine Gearbox
Gearbox Model: MG32.35 Marine Gearbox
Input Speed Range: 400 – 1800 RPM
Reduction Ratio: 1.9762 – 5.9286
Trans. Capacity: 0.490 – 1.470 kW / RPM
MGS |
FADA MGS70.76 Marine Gearbox
Gearbox Model: MGS70.76 Marine Gearbox
Input Speed Range: 400 – 1000 RPM
Reduction Ratio: 2.0000 – 3.9500
Trans. Capacity: 6.983 kW / RPM
FADA MGS60.66 Marine Gearbox
Gearbox Model: MGS60.66 Marine Gearbox
Input Speed Range: 400 – 1200 RPM
Reduction Ratio: 2.0000 – 3.9500
Trans. Capacity: 4.625 kW / RPM
FADA MGS52.59 Marine Gearbox
Gearbox Model: MGS52.59 Marine Gearbox
Input Speed Range: 400 – 1200 RPM
Reduction Ratio: 2.0000 – 3.9500
Trans. Capacity: 3.448 kW / RPM
FADA MGS49.54 Marine Gearbox
Gearbox Model: MGS49.54 Marine Gearbox
Input Speed Range: 400 – 1200 RPM
Reduction Ratio: 2.0000 – 3.9500
Trans. Capacity: 2.854 kW / RPM
FADA MGS45.49 Marine Gearbox
Gearbox Model: MGS45.49 Marine Gearbox
Input Speed Range: 400 – 1400 RPM
Reduction Ratio: 2.0000 – 3.9500
Trans. Capacity: 2.207 kW / RPM
FADA MGS42.45 Marine Gearbox
Gearbox Model: MGS42.45 Marine Gearbox
Input Speed Range: 400 – 1600 RPM
Reduction Ratio: 1.9714 – 3.9524
Trans. Capacity: 1.692 kW / RPM
FADA MGS39.41 Marine Gearbox
Gearbox Model: MGS39.41 Marine Gearbox
Input Speed Range: 400 – 1600 RPM
Reduction Ratio: 2.0000 – 3.9500
Trans. Capacity: 1.169 kW / RPM
FADA MGS36.39 Marine Gearbox
Gearbox Model: MGS36.39 Marine Gearbox
Input Speed Range: 400 – 1800 RPM
Reduction Ratio: 1.9714 – 3.9524
Trans. Capacity: 0.919 kW / RPM
