FADA GQ Series Gearbox
The input speed range of the FADA GQ Series marine gearbox is 1000 – 2500 RPM. The reduction ratio range is 1.02 – 3.65 and transfer capacity range is 0.098 – 1.545 kW/RPM.
FADA GQ Series marine gearbox is composed of Input coupling, control system, output coupling, oil cooler, oil filter, oil pressure gauge and other important components. FADA GQ Series marine gearbox can provide mechanical control system.
All of our FADA gearboxes are approved by CCS, and we are able to provide BV LR ABS DNV&GL RS and other classification societies based on customer requirement with extra cost.
As an official marine power pack packager of FADA, SeaMac provide complete propulsion system and power system for all kinds of ships all around the world. Mainly including marine engine, gearbox, shaft, propeller, marine genset, electric control lever system and other marine accessories. We also provide full life cycle services for all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages Of FADA GQ Marine Gearbox
- Gearbox novel structure, so that its use becomes very reliable. The excellent design makes the gearbox and engine arrangement more soft and smooth.
- Small in size, clear in weight. The ease of use and maintenance is fully considered in the design.
- With excellent machine performance, good design effectively reduce the noise, reduce the vibration.
- European standard manufacturing, making the structure strong and durable, smooth work.
- Excellent deceleration effect and bearing propeller thrust.
- Professional gearbox specialists and after-sales service, spare parts directly available from stock.
General Specifications of FADA Gearbox GQ Series
| Rated Speed: | 1000 – 2500 RPM |
| Actual Ratio: | 1.02 – 3.65 |
| Capacity: | 0.098 – 1.545 kW / RPM |
| Net Weight: | 235 – 2080 kg |
FADA GQ Series Marine Gearbox
This is a list of all of FADA GQ series marine gearbox.
FADA GQ2100/1 Marine Gearbox
Gearbox Model: GQ2100/1 Marine Gearbox
Input Speed Range: 1000 – 2300 RPM
Nominal Ratio: 2.0 – 3.5
Trans. Capacity: 1.324 – 1.545 kW / RPM
FADA GQ2100 Marine Gearbox
Gearbox Model: GQ2100 Marine Gearbox
Input Speed Range: 1000 – 2300 RPM
Nominal Ratio: 1.5 – 2.8
Trans. Capacity: 1.398 – 1.545 kW / RPM
FADA GQ2000/1 Marine Gearbox
Gearbox Model: GQ2000/1 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 2.0 – 3.2
Trans. Capacity: 1.250 – 1.471 kW / RPM
FADA GQ2000 Marine Gearbox
Gearbox Model: GQ2000 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 1.5 – 2.8
Trans. Capacity: 1.250 – 1.471 kW / RPM
FADA GQ1700/1 Marine Gearbox
Gearbox Model: GQ1700/1 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 2.0 – 3.2
Trans. Capacity: 1.030 – 1.250 kW / RPM
FADA GQ1700 Marine Gearbox
Gearbox Model: GQ1700 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 1.5 – 2.8
Trans. Capacity: 1.030 – 1.250 kW / RPM
FADA GQ1380/1 Marine Gearbox
Gearbox Model: GQ1380/1 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 2.0 – 3.2
Trans. Capacity: 0.900 – 1.030 kW / RPM
FADA GQ1380 Marine Gearbox
Gearbox Model: GQ1380 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 1.5 – 3.0
Trans. Capacity: 0.900 – 1.030 kW / RPM
FADA GQ1000/1 Marine Gearbox
Gearbox Model: GQ1000/1 Marine Gearbox
Input Speed Range: 1000 – 2300 RPM
Nominal Ratio: 2.0 – 3.2
Trans. Capacity: 0.735 kW / RPM
FADA GQ1000 Marine Gearbox
Gearbox Model: GQ1000 Marine Gearbox
Input Speed Range: 1000 – 2300 RPM
Nominal Ratio: 1.2 – 2.9
Trans. Capacity: 0.650 – 0.735 kW / RPM
FADA GQ750/1 Marine Gearbox
Gearbox Model: GQ750/1 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 2.5 – 3.7
Trans. Capacity: 0.490 – 0.554 kW / RPM
FADA GQ750 Marine Gearbox
Gearbox Model: GQ750 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.3 – 3.0
Trans. Capacity: 0.490 – 0.554 kW / RPM
FADA GQ500/1 Marine Gearbox
Gearbox Model: GQ500/1 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 2.0 – 3.0
Trans. Capacity: 0.405 kW / RPM
FADA GQ500 Marine Gearbox
Gearbox Model: GQ500 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.0 – 2.5
Trans. Capacity: 0.382 – 0.405 kW / RPM
FADA GQ400/1 Marine Gearbox
Gearbox Model: GQ400/1 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 2.0 – 3.5
Trans. Capacity: 0.331 kW / RPM
FADA GQ400 Marine Gearbox
Gearbox Model: GQ400 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.0 – 2.5
Trans. Capacity: 0.294 – 0.331 kW / RPM
FADA GQ300/1 Marine Gearbox
Gearbox Model: GQ300/1 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.5 – 3.5
Trans. Capacity: 0.221 – 0.257 kW / RPM
FADA GQ300 Marine Gearbox
Gearbox Model: GQ300 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.0 – 2.5
Trans. Capacity: 0.235 – 0.257 kW / RPM
FADA GQ250 Marine Gearbox
Gearbox Model: GQ250 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.0 – 2.8
Trans. Capacity: 0.125 – 0.184 kW / RPM
FADA GQ200/1 Marine Gearbox
Gearbox Model: GQ200/1 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 2.0 – 3.5
Trans. Capacity: 0.132 – 0.147 kW / RPM
FADA GQ200 Marine Gearbox
Gearbox Model: GQ200 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.5 – 2.5
Trans. Capacity: 0.132 – 0.147 kW / RPM
FADA GQ150 Marine Gearbox
Gearbox Model: GQ150 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.0 – 3.0
Trans. Capacity: 0.098 – 0.110 kW / RPM
