FADA High Speed-Light Duty Gearbox

FADA High Speed-Light Duty Gearbox products can be divided into GQ series.
FADA High Speed-Light Duty Gearbox have the ability to reducing speed, ahead and astern, clutching and disclutching and carrying the propeller thrust.
The said gearbox is somewhat new in construction, reliable in operation, smooth in engaging, light in weight, small in bulk, easy in maintenance and durable in application. The said gearbox is somewhat new in construction, reliable in operation, smooth in engaging, light in weight, small in bulk, easy in maintenance and durable in application. The transfer capacity ranges from 0.098 kW /rpm to 1.545 kW /rpm, with a ratio of 1.02 – 3.65.
The said products can be used in passenger or cargo boats, fishing boats, tow boats, tugs and high-speed vessels etc., which are perfect selections to make the engine in good condition and to get high efficiency.
As an official marine power pack packager of FADA, SeaMac provide complete propulsion system and power system for all kinds of ships all around the world. Mainly including marine engine, gearbox, shaft, propeller, marine genset, electric control lever system and other marine accessories. We also provide full life cycle services for all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

Advantages Of High Speed-Light Duty Marine Gearboxe

  1. Gearbox novel structure, so that its use becomes very reliable. The excellent design makes the gearbox and engine arrangement more soft and smooth.
  2. Small in size, clear in weight. The ease of use and maintenance is fully considered in the design.
  3. With excellent machine performance, good design effectively reduce the noise, reduce the vibration.
  4. European standard manufacturing, making the structure strong and durable, smooth work.
  5. Excellent deceleration effect and bearing propeller thrust.
  6. Professional gearbox specialists and after-sales service, spare parts directly available from stock.

Find High Speed-Light Duty Gearboxs by Series

This is the list of all series of FADA High Speed-Light Duty Gearboxs.

GQ |

FADA GQ2100/1 Marine Gearbox

Gearbox Model: GQ2100/1 Marine Gearbox
Input Speed Range: 1000 – 2300 RPM
Nominal Ratio: 2.0 – 3.5
Trans. Capacity: 1.324 – 1.545 kW / RPM

FADA GQ2100 Marine Gearbox

Gearbox Model: GQ2100 Marine Gearbox
Input Speed Range: 1000 – 2300 RPM
Nominal Ratio: 1.5 – 2.8
Trans. Capacity: 1.398 – 1.545 kW / RPM

FADA GQ2000/1 Marine Gearbox

Gearbox Model: GQ2000/1 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 2.0 – 3.2
Trans. Capacity: 1.250 – 1.471 kW / RPM

FADA GQ2000 Marine Gearbox

Gearbox Model: GQ2000 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 1.5 – 2.8
Trans. Capacity: 1.250 – 1.471 kW / RPM

FADA GQ1700/1 Marine Gearbox

Gearbox Model: GQ1700/1 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 2.0 – 3.2
Trans. Capacity: 1.030 – 1.250 kW / RPM

FADA GQ1700 Marine Gearbox

Gearbox Model: GQ1700 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 1.5 – 2.8
Trans. Capacity: 1.030 – 1.250 kW / RPM

FADA GQ1380/1 Marine Gearbox

Gearbox Model: GQ1380/1 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 2.0 – 3.2
Trans. Capacity: 0.900 – 1.030 kW / RPM

FADA GQ1380 Marine Gearbox

Gearbox Model: GQ1380 Marine Gearbox
Input Speed Range: 1000 – 2100 RPM
Nominal Ratio: 1.5 – 3.0
Trans. Capacity: 0.900 – 1.030 kW / RPM

FADA GQ1000/1 Marine Gearbox

Gearbox Model: GQ1000/1 Marine Gearbox
Input Speed Range: 1000 – 2300 RPM
Nominal Ratio: 2.0 – 3.2
Trans. Capacity: 0.735 kW / RPM

FADA GQ1000 Marine Gearbox

Gearbox Model: GQ1000 Marine Gearbox
Input Speed Range: 1000 – 2300 RPM
Nominal Ratio: 1.2 – 2.9
Trans. Capacity: 0.650 – 0.735 kW / RPM

FADA GQ750/1 Marine Gearbox

Gearbox Model: GQ750/1 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 2.5 – 3.7
Trans. Capacity: 0.490 – 0.554 kW / RPM

FADA GQ750 Marine Gearbox

Gearbox Model: GQ750 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.3 – 3.0
Trans. Capacity: 0.490 – 0.554 kW / RPM

FADA GQ500/1 Marine Gearbox

Gearbox Model: GQ500/1 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 2.0 – 3.0
Trans. Capacity: 0.405 kW / RPM

FADA GQ500 Marine Gearbox

Gearbox Model: GQ500 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.0 – 2.5
Trans. Capacity: 0.382 – 0.405 kW / RPM

FADA GQ400/1 Marine Gearbox

Gearbox Model: GQ400/1 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 2.0 – 3.5
Trans. Capacity: 0.331 kW / RPM

FADA GQ400 Marine Gearbox

Gearbox Model: GQ400 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.0 – 2.5
Trans. Capacity: 0.294 – 0.331 kW / RPM

FADA GQ300/1 Marine Gearbox

Gearbox Model: GQ300/1 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.5 – 3.5
Trans. Capacity: 0.221 – 0.257 kW / RPM

FADA GQ300 Marine Gearbox

Gearbox Model: GQ300 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.0 – 2.5
Trans. Capacity: 0.235 – 0.257 kW / RPM

FADA GQ250 Marine Gearbox

Gearbox Model: GQ250 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.0 – 2.8
Trans. Capacity: 0.125 – 0.184 kW / RPM

FADA GQ200/1 Marine Gearbox

Gearbox Model: GQ200/1 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 2.0 – 3.5
Trans. Capacity: 0.132 – 0.147 kW / RPM

FADA GQ200 Marine Gearbox

Gearbox Model: GQ200 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.5 – 2.5
Trans. Capacity: 0.132 – 0.147 kW / RPM

FADA GQ150 Marine Gearbox

Gearbox Model: GQ150 Marine Gearbox
Input Speed Range: 1000 – 2500 RPM
Nominal Ratio: 1.0 – 3.0
Trans. Capacity: 0.098 – 0.110 kW / RPM
