Gearbox Model: JT900/1 Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 9.585 – 16.430
Trans. Capacity: 0.338 – 0.699 kW / RPM
FADA Medium-Heavy Duty Gearbox
FADA Medium-Heavy Duty Gearbox products can be divided into 900 series,1000 series,1100 series,1200 series, 1260 series, 1380 series, 1500 series,1600 series, 1700 series, 2200 series, 2800 series.
FADA Medium-Heavy Duty Gearbox have the ability to reducing speed, ahead and astern, clutching and dispatching and carrying the propeller thrust.
The gearbox has reliable operation, stable meshing, high conversion efficiency, good transmission performance, large rated propeller thrust, convenient maintenance and durability. The transfer capacity ranges from 0.338 kW /rpm to 2.0594 kW/rpm, with a ratio of 1.54:1-12.5:1.
As an official marine power pack packager of FADA, SeaMac provide complete propulsion system and power system for all kinds of ships all around the world. Mainly including marine engine, gearbox, shaft, propeller, marine genset, electric control lever system and other marine accessories. We also provide full life cycle services for all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of Medium-Heavy Duty Gearboxs
- Simple structure, fewer parts, small volume: easy to repair, installation.
- Customer selection is rich: to meet different categories of industrial machinery.
- Different engine layouts are required.
- Product upgrade with strong versatility: the customer interface is basically unchanged.
- Good reliability: long-term quality assurance does not decline.
- Good power performance: widely used.
- Low emissions: environmental protection.
Product chain rich: to meet the requirements of different stages of emissions, a variety of not.
Find Medium-Heavy Duty Gearboxs by Series
This is the list of all series of FADA Medium-Heavy Duty Gearboxs.
900 |
FADA JT900 Marine Gearbox
Gearbox Model: JT900 Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 4.6467 – 9.5212
Trans. Capacity: 0.441 – 0.800 kW / RPM
FADA JD900A Marine Gearbox
Gearbox Model: JD900A Marine Gearbox
Input Speed Range: 750 – 1600 RPM
Reduction Ratio: 3.955 – 5.944
Trans. Capacity: 0.600 – 0.706 kW / RPM
FADA J900A Marine Gearbox
Gearbox Model: J900A Marine Gearbox
Input Speed Range: 750 – 1600 RPM
Reduction Ratio: 1.963 – 4.063
Trans. Capacity: 0.629 – 0.700 kW / RPM
1000 |
FADA JT1000/1 Marine Gearbox
Gearbox Model: JT1000/1 Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 10.119 – 17.561
Trans. Capacity: 0.382 – 0.794 kW / RPM
1200 |
FADA JT1200 Marine Gearbox
Gearbox Model: JT1200 Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 6.124 – 9.015
Trans. Capacity: 0.846 – 1.014 kW / RPM
FADA JD1200 Marine Gearbox
Gearbox Model: JD1200 Marine Gearbox
Input Speed Range: 600 – 1600 RPM
Reduction Ratio: 3.9524 – 5.9412
Trans. Capacity: 0.735 – 1.014 kW / RPM
FADA J1200A Marine Gearbox
Gearbox Model: J1200A Marine Gearbox
Input Speed Range: 750 – 1500 RPM
Reduction Ratio: 2.56 – 4.45
Trans. Capacity: 0.930 kW / RPM
1260 |
FADA J1260 Marine Gearbox
Gearbox Model: J1260 Marine Gearbox
Input Speed Range: 600 – 1600 RPM
Reduction Ratio: 1.5278 – 4.4737
Trans. Capacity: 0.758 – 0.956 kW / RPM
1380 |
FADA JT1380/6 Marine Gearbox
Gearbox Model: JT1380/6 Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 11.0526 – 15.9721
Trans. Capacity: 0.800 – 1.030 kW / RPM
FADA JT1380/5A Marine Gearbox
Gearbox Model: JT1380/5A Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 8.98250 – 14.9350
Trans. Capacity: 0.765 – 1.030 kW / RPM
FADA JT1380/3 Marine Gearbox
Gearbox Model: JT1380/3 Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 7.5243 – 11.5180
Trans. Capacity: 0.814 – 1.014 kW / RPM
FADA JT1380/2 Marine Gearbox
Gearbox Model: JT1380/2 Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 9.5357 – 22.2588
Trans. Capacity: 0.410 – 1.014 kW / RPM
FADA JT1380/1 Marine Gearbox
Gearbox Model: JT1380/1 Marine Gearbox
Input Speed Range: 1000 – 1800 RPM
Reduction Ratio: 8.0795 – 18.5579
Trans. Capacity: 0.490 – 0.831 kW / RPM
1500 |
FADA JT1500/1 Marine Gearbox
Gearbox Model: JT1500/1 Marine Gearbox
Input Speed Range: 600 – 1500 RPM
Reduction Ratio: 7.957 – 16.960
Trans. Capacity: 0.775- 1.250 kW / RPM
FADA JT1500 Marine Gearbox
Gearbox Model: JT1500 Marine Gearbox
Input Speed Range: 600 – 1600 RPM
Reduction Ratio: 4.9742 – 11.8095
Trans. Capacity: 0.846 – 1.250 kW / RPM
FADA JD1500A Marine Gearbox
Gearbox Model: JD1500A Marine Gearbox
Input Speed Range: 600 – 1600 RPM
Reduction Ratio: 3.000 – 5.941
Trans. Capacity: 0.886 – 1.200 kW / RPM
1700 |
FADA JD1700 Marine Gearbox
Gearbox Model: JD1700 Marine Gearbox
Input Speed Range: 600 – 1600 RPM
Reduction Ratio: 3.000- 5.941
Trans. Capacity: 1.03 – 1.25 kW / RPM
2200 |
FADA JT2200/1 Marine Gearbox
Gearbox Model: JT2200/1 Marine Gearbox
Input Speed Range: 600 – 1500 RPM
Reduction Ratio: 6.9543 – 13.6875
Trans. Capacity: 1.220 – 1.618 kW / RPM
FADA JT2200 Marine Gearbox
Gearbox Model: JT2200 Marine Gearbox
Input Speed Range: 600 – 1500 RPM
Reduction Ratio: 5.5135 – 10.8656
Trans. Capacity: 1.220 – 1.618 kW / RPM
FADA JD2200 Marine Gearbox
Gearbox Model: JD2200 Marine Gearbox
Input Speed Range: 600 – 1500 RPM
Reduction Ratio: 3.4583 – 6.0588
Trans. Capacity: 1.321 – 1.618 kW / RPM
FADA J2200 Marine Gearbox
Gearbox Model: J2200 Marine Gearbox
Input Speed Range: 600 – 1500 RPM
Reduction Ratio: 1.4571 – 4.4375
Trans. Capacity: 1.397 – 1.618 kW / RPM
2800 |
FADA JT2800/1 Marine Gearbox
Gearbox Model: JT2800/1 Marine Gearbox
Input Speed Range: 500 – 1400RPM
Reduction Ratio: 7.4858 – 12.4211
Trans. Capacity: 1.7200 – 2.0594 kW / RPM
FADA JT2800 Marine Gearbox
Gearbox Model: JT2800 Marine Gearbox
Input Speed Range: 500 – 1400RPM
Reduction Ratio: 5.0817 – 11.4895
Trans. Capacity: 1.4269 – 2.0594 kW / RPM
FADA JD2800 Marine Gearbox
Gearbox Model: JD2800 Marine Gearbox
Input Speed Range: 500 – 1400 RPM
Reduction Ratio: 3.6538:1 – 6.1053:1
Trans. Capacity: 1.7000 – 2.0594 kW / RPM
